- Size: 7.35*1.2*1.5m
- Place of Origin: Liaoning, China
- Brand Name: Haitian
- Model Number: 320
- Weight: 6000.000 kg
No | Item | Parameter | Note | |
1 | Suitable
Material | Type | Steel sheet |
|
Roller Shutter | Thickness: 0.7-1.0 mm |
| ||
2 | Product Specifications | Detail as the attached drawing | ||
3 | Power Requirement | Type | 380V/3PH/50HZ |
|
Main motor power(KW) | 3 |
| ||
Cutting power(KW) | 2.2 |
| ||
4 | Forming Speed(m/min) | 15-18 |
| |
6 | Forming Stand | 12 | Depend on actual design | |
7 | Forming Shaft Diameter(mm) | 65 | Depend on actual design | |
8 | Type of Cutting | Roll-formed and length-set cutting |
| |
9 | Control System | Mitsubishi PLC and inverter |
| |
10 | Run Out Table | 2mX3 |
| |
11 | Installation Dimension(m) | 8X1.5 | Without the panel length | |
12 | Total Weight(T) | 8 | Depend on actual design | |
